CSM-1701 SPECIFICATIONS
- Screen : 15.6” TFT LCD color touch screen
- Resolution : 1280 x 800 px
- Weight : 6kg
- Parameters : ECG, Respiration, Spo2, NIBP, IBP, Temperature, BIS, CO2, EEG, esCCO, Gases.
- Waveform : 15
- Dimensions : 341W x 294H x 204D mm
- Network interface : Standard
- Interbed: 20 beds
- Printing : 3 strokes (requires printer)
OTHER FEATURES
- 12-lead ECG analysis
- Gas Measurement with the GF Series Multi-Gas Unit
- Inter-bed function
- PWTT technology
- 2 and 4 channel BIS reading
- TOF on the monitor
- Option to expand more multicomments (2) or (4)
Additional Info
-
imagen de marca
Published in
Products
Tagged under
SPECIFICATIONS
- Screen: 5.7-inch touch
- Display modes: standard transport Parameters:
- ECG (12 leads), Respiration, PPI (up to 3 traces), SPO2, CO2, BIS, CO thermodilution curve.
- Number of waveforms: Maximum 09
- Battery time: 05 hours
- Dimensions: 147W x 194H x 94D mm
- Weight: 1.57 kg with battery
OTHER FEATURES
- Compact and lightweight
- Everything in one step
- Wireless data transmission
- esCCO (estimated continuous cardiac output)
- iNIBP CO2 Monitoring
- Flexible parameters with MULTI connectors
Additional Info
-
imagen de marca
Published in
Products
Tagged under
CSM-1502 SPECIFICATIONS
- Screen : 15.6” TFT LCD color touch screen
- Resolution : 1366 x 768 px
- Weight : 7kg
- Parameters : ECG, Respiration, Spo2, NIBP, IBP, Temperature, BIS, CO2, EEG, esCCO, Gases, TOF
- Waveform : 15
- Dimensions :403W x 302H x 204D mm
- Network interface : Standard
- Interbed: 20 beds
- Battery time: 150 minutes
- Printing : 3 strokes (requires printer)
OTHER FEATURES
- 12-lead ECG analysis
- Gas Measurement with the GF Series Multi-Gas Unit
- Inter-bed function
- PWTT technology
- 2 and 4 channel BIS reading
- TOF on the monitor
- Option to expand more multicomments (2) or (4)
Additional Info
-
imagen de marca
Published in
Products
Tagged under
CSM-1501 SPECIFICATIONS
- Screen : 12.1” TFT LCD color touch screen
- Resolution : 1280 x 800 px
- Weight : 6kg
- Parameters : ECG, Respiration, Spo2, NIBP, IBP, Temperature, BIS, CO2, EEG, esCCO, Gases, TOF
- Waveform : 15
- Dimensions : 341W x 294H x 204D mm
- Network interface : Standard
- Interbed: 20 beds
- Battery time: 150 minutes
- Printing : 3 strokes (requires printer)
OTHER FEATURES
- 12-lead ECG analysis
- Gas Measurement with the GF Series Multi-Gas Unit
- Inter-bed function
- PWTT technology
- 2 and 4 channel BIS reading
- TOF on the monitor
- Option to expand more multicomments (2) or (4)
Additional Info
-
imagen de marca
Published in
Products
Tagged under
ESPECITICATIONS
- Screen: 15” color LCD with TFT technology, touch
- Resolution: 1024 x 768 px
- Weight :7.4kg
- Waveform display mode: With moving eye hold or with fixed eye hold
- Waveform : Maximum 15
- Dimensions : W 430 x H 350 x D 172 mm
- External devices: CCO, SvO2, tcPOC,TOF,ventilator, anesthesia workstation, ICP.
- Arrhythmia memories : 8,192 events (16,384 events with optional QM-601P)
- Battery time: 1.0 hours
- Printing: 3 strokes (requires printer)
OTHER FEATURES
- 12-lead ECG analysis
- Gas Measurement with the GF Series Multi-Gas Unit
- Inter-bed function
- PWTT technology
- 2 and 4 channel BIS reading
- TOF on the monitor
- Option to expand more multicomments (2) or (4)
Additional Info
-
imagen de marca
Published in
Products
Tagged under
SPECIFICATIONS
- Screen: 12.1” color LCD with TFT technology, touch
- Resolution : 800 x 600 px
- Weight :6.2kg
- Waveform display mode : With moving eye hold or with fixed eye hold
- Waveform : Maximum 14
- Dimensions: W 370 x H 310 x D 172 mm
- External devices : CCO, SvO2, tcPOC,TOF,ventilator, anesthesia workstation, ICP
- Arrhythmia memories: 8,192 events (16,384 events with optional QM-601P)
- Battery time: 1.5 hours
- Printing: 3 strokes (requires printer)
OTHER FEATURES
- 12-lead ECG analysis
- Gas Measurement with the GF Series Multi-Gas Unit
- Inter-bed function PWTT technology
- 2 and 4 channel BIS reading
- TOF on the monitor
- Option to expand more multicomments (2) or (4)
Additional Info
-
imagen de marca
Published in
Products
Tagged under
SPECIFICATIONS :
- 12.1" size
- Intuitive touch screen operation
- Simple operation
- 120 hours of synchronized review data
- Interbed allows quick access to any patient in the network
- Reliability, quality and performance
Additional Info
-
imagen de marca
Published in
Products
Tagged under
SPECIFICATIONS
- Screen : Color TFT-LCD 10”
- Weight : 3.3 kg.
- Waveform : 4
- Basic parameters : ECG, RESP, NIBP. SpO2, TEMPERATURE
- Battery : 6 hours of operation
- Interbed : 8 beds
- Trend chart: 120 hours
- Alarm history: 120 hours
- Rate Type : Bedside monitor to monitor heart rate, ST level VPC premature ventricular contraction rate, SpO 2 respiratory rate values, pulse, body temperature, blood pressure values non-invasively.
- iNIBP is Nihon Kohden's unique algorithm for measuring PNI during inflation. Provides quick and painless NIBP measurement
- PWTT triggered NIBP measurements, increases the chance of detecting a sudden change in blood pressure
- NIBP systolic pressure alarm for 8 seconds
Additional Info
-
imagen de marca
Published in
Products
Tagged under
Additional Info
- Url marca https://www.mipm.com/de
Published in
Marcas
Diseñada para monitorear pacientes durante los exámenes de MRI. Mide continuamente la saturación de oxígeno, así como arterial no invasiva.
- Configuración flexible
- Sensor de oximetría de pulso inalámbrico
- Adaptador de dedo en tres tamaños
- Pantalla táctil de 7”
- Control remoto infrarrojo
ACCESORIOS
- Tubo de presión NIBP long: 4m
- Brazalete NIBP Bebé 9-15 cms
- Brazalete NIBP Niño 14-21.5 cms
- Brazalete NIBP Adulto pequeño 20.5-28.5 cms
- Brazalete NIBP Adulto 27-35 cms
- Brazalete NIBP Adulto grande 34-44 cms
- Brazalete NIBP Muslo 42-52 cms
